Usage notes:
This product is intended to be used only on racing vehicles on closed courses, and not for use on roads or vehicles otherwise subject to emission control requirements. Please check legality of aftermarket products with your country, local state, county, city authorities before purchasing. In USA, this product should not be used on any vehicles that is registered or licensed for use on public roads.
The turbocharged V-twin was large, heavy, complex and expensive. We doesn't provide ihi turbo specs products or service, please contact them directly and verify their companies info carefully. The CX500 Turbo with which Honda stunned the motorcycle world in 1982 was one of the least likely bikes ever to be put into production. Part number Aplication C.H.R.A. Service kit A/R Replaces by AI71 RHB31-50001P9NFBRS255AZ VA110036 ISUZU 9 AY49 RHB31 NB130031 YANMAR NZ852836 NB139837 VA110030 AY68 RHB31-50001P12NFBRS255AZ VA110052 YANMAR 12 CIAT RHB31-50001P7NFBRS2416DZ VA110098 ISUZU 7 CY26 RHB31-50001P12NFBRS255AZ NB130015 YANMAR NZ852836 NB139837 12 VA110024.
Ihi Turbo found in: Turbocharger, Turbocharger and Installation Accessory Kit, Turbocharger Mounting Gasket Set, Turbocharger Compressor Wheel, IHI GM3 Turbo 6.5L Diesel Engine, 6.6L Diesel LB7 Engine IHI Turbo with OEM Number. MAN diesel & turbo Turbocharger Programme 2010. 445100 MAN NA MAN diesel & Turbo NA Turbochargers Project Guide. 445110 NA48/S MAN (Kawasaki MAN B&W) turbocharger NA48/S Operating manual with spare parts list. 445120 NA48 MAN B&W NA 48 Turbocharger - Instruction Manual with Drawings and Part Numbers. TURBO INFORMATION TURBO BRAND: IHI / CLOVER TURBO MODEL: RHE62W TURBO CONDITION: NEW This is a genuine IHI turbocharger and is brand new - it comes complete with 12 months warranty and after sales service.
This turbocharger can be used as a trustworthy heavy-duty stock replacement , or for competitions with modifications of engine and peripheral accessories.
PRODUCT FEATURES
Compressor system has the high efficient function 'Abradable seal' and 'Larger impeller'. It will make stable & more compressed air to feed.
And 'Twin scroll type' turbine housing is same as mass production, so it can support a wide range of engine speed.
Wastegate actuator could be adjusted with using 'turnbuckle adjuster'.
- Precise machined aluminum forged big compressor wheel
- The appropriate shaped larger compressor shroud adopts an abrade-able seal structure that further improves charging efficiency.
- Turnbuckle adjustable wastegate actuator
- Bolt-on Installation
- Gaskets are excluded
- Engine and peripheral parts modifications will be needed to soup up the performance more.
- Installation:
- BOLT-ON
- Recommend for racing vehicle:
- ECU AdjustmentInlet & Exhaust Upgrade
Applicable model :
VF49 adopted model
[SUBARU GENUINE P/N: 14411AA690]
SUBARU WRX STI
GRB & GVB (Except 'Spec C', 'R205', 'S206')/ VAB (Except 'S20#', 'RA-R')
P/N : F56CAC-SP017
| Turbo model | Assumed Max Power | Compressor Wheel | Turbine Wheel | ||
|---|---|---|---|---|---|
| In Dia (mm) | Ex Dia (mm) | In Dia (mm) | Ex Dia (mm) | ||
| OEM Turbo | - | 46.5 | 60 | 53 | 48 |
| IHI Turbo Performance | up to 400 ps | 49.6 | 65 | 53 | 48 |
OUTPUT
TEST CAR
WRX STI (VAB)
ENGINE
EJ20 (2.0L)
Ihi Turbo Repair Manual Pdf
ECU
FLASH REPROGRAMED STOCK UNIT
Ihi Turbo Repair Manual Parts
FUEL SYSTEM
STOCK
IGNITION SYSTEM
STOCK
MODIFICATION
Ihi Rhb5 Turbo
HEADER & EXHAUST SYSTEM (Low and mid speed emphasized type), AIR FILTER, BOOST CONTROLLER, etc.
Note
The results are an example. The output is not guaranteed.
ADJUSTMENT
1. Actuator
Ihi Turbo Rhf5 Wheel
If the turbocharger unit which you select has the adjustable turn-buckle actuator, please use precise boost gauge and assure to fasten the nuts of the turn-buckle function when adjust it.2. Boost pressure control
To control boost pressure, aftermarket boost controller is necessary separately.
In case of racing use:
If actual boost pressure will be increased much enough, although using boost controller, it caused by exhaust gas flow volume is exceeding wastegate capacity, and must keep back pressure with using smaller size exhaust pipes or must prepare additional wastegate function to fix it.
3. Engine control parameters
If the car is recommended to use regular gasoline originally, please feed premium gasoline when adjust ignition timing and so on to avoid engine blow caused by knock.NOTE
- When attach this turbocharger, the car might be prohibited by car regulation depends on peripheral modification spec.
- This products aiming to make engine high performance and might make low durability.
- IHI Turbo do not take any responsibility or liability for any damage or loss caused through using the product.
- Installation instruction manual for each products is not included the products. Installation of the product should be performed by a person with appropriate qualifications and knowledge with follow the method described in the vehicle's service manual.
- The information posted on this web page is subject to change without notice.
CONTACT US
Any inquiries and orders, please contact our local distributors.
